Intel Core i7-13700K 13th Generation, 3.4 GHz, 16-Core LGA 1700 Processor

Hybrid Core Design

Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor's Efficient-cores for multitasking

Intel Thread Director

The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.

PCIe 4.0 & 5.0

This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices

Integrated Graphics

Driven by Intel Xe architecture, the integrated Intel UHD 770 Graphics delivers fast, rich 3D performance for high-quality visuals with support for either one 7680 x 4320 resolution 8K monitor or up to four 3840 x 2160 resolution 4K displays with high-dynamic range.

Gaussian & Neural Accelerator 3.0

Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats

Intel Deep Learning Boost

Accelerates AI inference to improve performance for deep learning workloads

General

CPU Model

Intel Core i7-13700K (13th Gen)

CPU Socket

LGA 1700

Manufacturing Process

10 nm

Maximum CPU Configuration

1S

Maximum Number of PCIe Lanes

16 (Revision 5.0)

4 (Revision 4.0)

Unlocked

Yes

Performance

Number of Cores

16 (8 x P-Cores + 8 x E-Cores)

Number of Threads

24

Base Clock Speed

P-Core: 3.4 GHz

E-Core: 2.5 GHz

Maximum Boost Speed

P-Core Turbo: 5.3 GHz

E-Core Turbo: 4.2 GHz

L3 Cache

30 MB

Memory Support

Maximum Capacity

128 GB

Memory Support

DDR5 5600 MHz

DDR4 3200 MHz

ECC Memory

Yes

Channel Architecture

Dual Channel

Optane Memory Support

Yes

Power

Thermal Design Power (TDP)

125 W

Included Thermal Solution

None

Maximum Temperature

212°F / 100°C

Thermal Monitoring Technologies

Yes

Technology

AES Support

Yes

Extension

AVX 2.0, AVX-512, SSE 4.1/4.2

Instruction Set

64-Bit

Virtualization

Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT)

vPro Support

Yes

Performance Technologies

Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Stable Image Platform Program, Turbo Boost 2.0, Turbo Boost Max 3.0

Security Technologies

Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology

Video Technologies

Clear Video, Clear Video HD, InTru 3D, Quick Sync Video

Integrated Graphics

Integrated Graphics

Intel UHD Graphics 770

Maximum Resolution Support

7680 x 4320 at 60 Hz

Supported APIs

DirectX: 12

OpenGL: 4.5

Number of Displays

4

Output Support

DisplayPort, HDMI

Base Clock Speed

300 MHz

Maximum Boost Speed

1.45 GHz
