SanDisk Professional 160 TB G-RAID Shuttle 8 8-Bay Thunderbolt 3 RAID Array (8 x 20 TB)

SanDisk Professional 160 TB G-RAID Shuttle 8 8-Bay Thunderbolt 3 RAID Array (8 x 20 TB)

Colossal Capacity, Transportable Design

With a capacity of 160 TB of high-powered RAID storage in an easy-to-transport design, content creators get a premium solution for their demanding workflows, whether on location or in the studio.

High-Speed Data Transfers

With read speeds of up to 1900 MB/s, write speeds of up to 2000 MB/s, and support for multi-stream 4K, 8K, and VR workflows, you can quickly move or copy all your media so you can spend less time waiting and more time creating with high-speed data transfer using the 40 Gb/s Thunderbolt 3 or 10 GB/s USB-C ports.

Built-In Hardware RAID

For balanced performance, the G-RAID Shuttle 8 comes formatted for macOS 10.15 and later and is configured as RAID 5. It also supports RAID 0, 1, 6, 10, 50, 60, and JBOD for greater flexibility and may be reformatted for Windows 10.

Removable, Reliable 7200 RPM Ultrastar Enterprise-Class Drives

For all your demanding workloads and mission critical footage, you can depend on the power and enhanced reliability of eight removable Ultrastar Enterprise-class 7200 RPM hard drives inside.

Daisy-Chaining for up to 5 Additional Devices

With dual Thunderbolt 3 ports, you can conveniently daisy chain up to 5 additional devices, keeping you connected to multiple drives, 4K displays, and more, through a single connection to your computer.

USB Power Delivery

With support for up to 85W of USB Power Delivery through the USB-C port, this drive can charge your compatible MacBook or MacBook Pro without having to take a separate MacBook charger out of your bag.

Drives

Storage Capacity

160 TB

Included Drives

8x 20 TB SATA III 3.5" HDD 7200 RPM

RAID

Yes: Supported RAID Modes: 0 / 1 / 5 / 6 / 10 / 50 / 60 / 1E / JBOD (Preconfigured in RAID 5)

Transfer Rates

1900 MB/s (Read in RAID Mode Unspecified)

2000 MB/s (Write in RAID Mode Unspecified)

1690 MB/s (Read in RAID 5)

1490 MB/s (Write in RAID 5)

General

Number of Bays

8x 3.5" SATA III

Inputs/Outputs

2x USB-C Thunderbolt 3 (40 Gb/s)

Media Card Slots

No

PCI Expansion

No

Software

OS Compatibility

macOS 11 or Later

Windows 10 or Later

Default OS Support

macOS

Security

Encryption

No

Security Features

No

Electrical

Input Power

100 to 240 VAC, 50 / 60 Hz at 2 to 4 A

Physical

Operating Conditions

41 to 95°F / 5 to 35°C at 5 to 80% Humidity

Certifications

BIS, BSMI, CE, EAC, FCC-ICES, KC, RCM, SABER, UKCA, VCCI

Cooling

2x Fans

Weight

27.3 lb / 12.4 kg
