Standards
|
Wi-Fi 6
|
|
IEEE 802.11ax/ac/n/a 5 GHz
|
|
IEEE 802.11ax/n/b/g 2.4 GHz
|
Wi-Fi Speeds
|
AX6600
|
|
5 GHz: 4804 Mbps (802.11ax, HE160)
|
|
5 GHz: 1201 Mbps (802.11ax)
|
|
2.4 GHz: 574 Mbps (802.11ax)
|
Wi-Fi Range
|
4 Bedroom Houses
|
|
8× Detachable High-Performance Antennas
|
|
Multiple antennas form a signal-boosting array to cover more directions and large areas
|
|
Beamforming
|
|
Concentrates wireless signal strength towards clients to expand WiFi range
|
|
High-Power FEM
|
|
Improves transmission power to strengthen signal coverage
|
|
4T4R
|
|
Multiple streams in the same band strengthen the fault tolerance in transmission
|
Wi-Fi Capacity
|
Very High
|
|
Tri-Band
|
|
Allocate devices to different bands for optimal performance
|
|
4×4 MU-MIMO
|
|
Simultaneously communicates with multiple MU-MIMO clients
|
|
OFDMA
|
|
Simultaneously communicates with multiple Wi-Fi 6 clients
|
|
Airtime Fairness
|
|
Improves network efficiency by limiting excessive occupation
|
|
DFS
|
|
Access an extra band to reduce congestion
|
|
8 Streams
|
|
Connect your devices to more bandwidth
|
Working Modes
|
Router Mode
|
|
Access Point Mode
|
Processor
|
1.5 GHz Quad-Core CPU
|
Ethernet Ports
|
1× 2.5 Gbps WAN/LAN Port
|
|
1× Gigabit WAN/LAN Port
|
|
3× Gigabit LAN Ports
|
USB Support
|
1× USB 3.0 Port
|
|
1× USB 2.0 Port
|
|
Supported Partition Formats:
|
|
NTFS, exFAT, HFS+, FAT32
|
|
Supported Functions:
|
|
Apple Time Machine
|
|
FTP Server
|
|
Media Server
|
|
Samba Server
|
Buttons
|
Wi-Fi On/Off Button
|
|
Power On/Off Button
|
|
LED On/Off Button
|
|
WPS Button
|
|
Reset Button
|
Power
|
12 V ⎓ 5 A
|
WiFi Encryption
|
WPA
|
|
WPA2
|
|
WPA3
|
|
WPA/WPA2-Enterprise (802.1x)
|
Network Security
|
SPI Firewall
|
|
Access Control
|
|
IP & MAC Binding
|
|
Application Layer Gateway
|
|
HomeCare Antivirus
|
|
Malicious Site Checker
|
|
Port Intrusion Prevention
|
|
Infected Device Isolation
|
|
Notification and Log
|
Guest Network
|
2× 5 GHz Guest Network
|
|
1× 2.4 GHz Guest Network
|
VPN Server
|
OpenVPN
|
|
PPTP
|
Protocols
|
IPv4
|
|
IPv6
|
Game Center
|
Game Accelerator
|
|
Detects and optimizes gaming streams to keep latency as low as possible
|
|
Game Statistics
|
|
Check real-time latency, system utilization, and game duration on a redesigned dashboard to tweak every detail
|
|
Game Protector
|
|
Keep your accounts and system safe with HomeCare antivirus protection
|
Service Kits
|
HomeCare
|
Parental Controls
|
HomeCare Parental Controls
|
|
Custom Profiles
|
|
Content Filtering
|
|
App Block
|
|
URL Filtering
|
|
Time Limit
|
|
Time Schedule (Bedtime)
|
|
Log Insight
|
WAN Types
|
Dynamic IP
|
|
Static IP
|
|
PPPoE
|
|
PPTP
|
|
L2TP
|
Quality of Service
|
Game Accelerator QoS.
|
|
QoS by Device
|
|
HomeCare QoS
|
|
QoS by Application
|
Cloud Service
|
Auto Firmware Upgrade
|
|
OTA Firmware Upgrade
|
|
TP-Link ID
|
|
DDNS
|
NAT Forwarding
|
Port Forwarding
|
|
Port Triggering
|
|
DMZ
|
|
UPnP
|
IPTV
|
IGMP Proxy
|
|
IGMP Snooping
|
|
Bridge
|
|
Tag VLAN
|
DHCP
|
Address Reservation
|
|
DHCP Client List
|
|
Server
|
DDNS
|
TP-Link
|
|
NO-IP
|
|
DynDNS
|
Management
|
Tether App
|
|
Webpage
|
