TP-Link TL-SG2210MP JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+

150 W PoE Budget

8× 802.3at/af-compliant PoE+ ports with a total power supply of 150 W

Full Gigabit Ports

8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.

Integrated into Omada SDN

Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.

Centralized Management

Cloud access and Omada app for ultra convenience and easy management.

Robust Security Strategies

IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.

Optimize Voice and Video Applications

L2/L3/L4 QoS and IGMP snooping.

Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p

Interface

8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX)

2× 100/1000 Mbps SFP Slots

Network Media

10BASE-T: UTP/STP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m)

100BASE-FX: MMF, SMF

1000BASE-X: MMF, SMF

Fan Quantity

1

Physical Security Lock

Yes

Power Supply

100-240V AC, 50/60Hz

PoE+ Ports(RJ45)

Standard: 802.3at/af compliant

PoE+ Ports: 8 Ports

Power Supply: 150 W

PoE Ports (RJ45)

Standard: 802.3at/af compliant

PoE+ Ports: 8 Ports

PoE Power Budget: 150 W

Dimensions ( W x D x H )

11.6 x 7.1 x 1.7 in
(294 x 180 x 44 mm)

Mounting

Desktop,
13" or 19" 1U rack mountable

Max Power Consumption

12.2 W (110 V / 60 Hz with no PD connected)

173.9 W (110 V / 60 Hz with 150 W PD connected)

Max Heat Dissipation

41.6 BTU/h (with no PD connected)

539.4 BTU/h (with 150 W PD connected)

Performance

Switching Capacity

20 Gbps

Packet Forwarding Rate

14.9 Mpps

MAC Address Table

8K

Packet Buffer Memory

4.1 Mbit

Jumbo Frame

9 KB
