MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Gaming Motherboard - Black

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Gaming Motherboard - Black

MSI MAG B650 TOMAHAWK WIFI DDR5 AMD AM5 ATX Gaming Motherboard

MSI MAG B650 TOMAHAWK WIFI

Supports AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors

Supports DDR5 Memory, up to 7600+(OC) MHz

Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works

2.5G LAN and Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection

Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs

Lightning USB 20G: Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1

AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience

What are the benefits of MSI MAG B650 TOMAHAWK Gaming Motherboard ?

  • Supports AMD Ryzen 7000, 8000, and 9000 series processors

  • High-speed DDR5 memory support up to 7600+ MHz (OC)

  • Advanced thermal design with extended heatsinks for stable performance

  • M.2 Shield Frozr helps maintain SSD performance

  • Fast and stable networking with 2.5G LAN and Wi-Fi 6E

  • High-speed PCIe Gen 4 M.2 for faster SSD performance

  • Ultra-fast USB 20Gbps transfer speed

  • Studio-grade audio quality for immersive experience

Specification

Chipset

AMD B650

CPU

Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5

Memory

4x DDR5, Maximum Memory Capacity 256GB
Memory Support DDR5 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
1DPC 1R Max speed up to 7600+ MHz
1DPC 2R Max speed up to 6400+ MHz
2DPC 1R Max speed up to 6400+ MHz
2DPC 2R Max speed up to 5400+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports AMD EXPO

Onboard Graphics

1x HDMI
Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 8K 60Hz

Slot

2x PCI-E x16 slot
Supports x16/x2 (For Ryzen 9000/ 7000 Series processors)
Supports x8/x2 (For Ryzen 8700/ 8600/ 8400 Series processors)
Supports x4/x2 (For Ryzen 8500/ 8300 Series processors)
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)

Audio

Realtek ALC4080 Codec
7.1-Channel High Performance Audio
Supports S/PDIF output
Supports up to 32-Bit/384 kHz playback on front panel

Storage

3x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
6x SATA 6G
The M2_2 slot will be unavailable when using Ryzen 8500/ 8300 Series processor
** M2_3 & PCI_E2 share the bandwidth. M2_3 will run at x2 speed and PCI_E2 will run at x2 speed when installing devices in both slots.

USB

2x USB 2.0 (Rear)
4x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
3x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Front)
1x USB 20Gbps Type C (Rear)

LAN

Realtek RTL8125BG 2.5Gbps LAN

Internal IO

1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
6x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports

WIRELESS LAN & BLUETOOTH

Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX
Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz bands
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.3

LED FEATURE

4x EZ Debug LED

PCB Info

 ATX
243.84mmx304.8mm
