TP-Link TL-WA1201 AC1200 Wireless Access Point
TP-Link TL-WA1201 AC1200 Wireless Access Point
 |
Higher speeds with MU-MIMO Equipped with the latest 802.11ac Wave 2 MU-MIMO technology, the TL-WA1201 easily delivers dual-band Wi-Fi speeds of up to 1200 Mbps to multiple devices at the same time. |
 |
PoE for easy installation TL-WA1201 supports passive PoE power supplies, it can be powered by the provided PoE adapter, making deployment easy and flexible. |
 |
Enhanced Wi-Fi Coverage Four external antennas equipped with Beamforming technology focus Wi-Fi signals to your devices to extend reliable Wi-Fi to every corner of your home or office, even over long distances. |
Specifications:
|
Interface |
1× 10/100/1000 Mbps Ethernet Port |
|
|
(Supports Passive PoE) |
|
Button |
Power On/Off Button, WPS Button, Reset Button |
|
External Power Supply |
12V/1.5A |
|
Wireless Standards |
IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz |
|
Dimensions ( W x D x H ) |
225×145.5×37 in (400×255×72 mm) |
|
Antenna Type |
4 Fixed High Performance Antennas |
|
WIRELESS FEATURES |
|
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz |
|
Reception Sensitivity |
5 GHz: |
|
|
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm |
|
|
11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm |
|
|
11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm |
|
|
11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm |
|
|
|
|
|
2.4 GHz: |
|
|
11g 54Mbps: -78 dBm |
|
|
11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm |
|
|
11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm |
|
Transmit Power |
CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz) |
|
|
FCC: <30dBm(2.4GHz&5GHz) |
|
Wireless Modes |
Access Point, Range Extender, Client, Multi-SSID |
|
Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control |
|
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions |
|
DHCP |
Server, DHCP Client List |
|
Quality of Service |
WMM |
|
Advanced Functions |
Captive Portal |
|
OTHERS |
|
|
Certification |
CE, FCC, RoHS |
|
Package Contents |
Wireless Access Point TL-WA1201 |
|
|
Power Adapter |
|
|
RJ45 Ethernet Cable |
|
|
Quick Installation Guide |
|
|
PoE Power Injector |
|
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, |
|
|
10, MAC OS, NetWare, UNIX or Linux |
|
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other |
|
|
Java-enabled browser |
|
Environment |
Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F) |
|
|
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
|
|
Operating Humidity: 10%~90% non-condensing |
|
|
Storage Humidity: 5%~90% non-condensing |
|
Protocol Support |
IPv4, IPv6 |
Original: $46.59
-65%$46.59
$16.31Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
TP-Link TL-WA1201 AC1200 Wireless Access Point
|
Higher speeds with MU-MIMO Equipped with the latest 802.11ac Wave 2 MU-MIMO technology, the TL-WA1201 easily delivers dual-band Wi-Fi speeds of up to 1200 Mbps to multiple devices at the same time. |
|
PoE for easy installation TL-WA1201 supports passive PoE power supplies, it can be powered by the provided PoE adapter, making deployment easy and flexible. |
|
Enhanced Wi-Fi Coverage Four external antennas equipped with Beamforming technology focus Wi-Fi signals to your devices to extend reliable Wi-Fi to every corner of your home or office, even over long distances. |
Specifications:
|
Interface |
1× 10/100/1000 Mbps Ethernet Port |
|
|
(Supports Passive PoE) |
|
Button |
Power On/Off Button, WPS Button, Reset Button |
|
External Power Supply |
12V/1.5A |
|
Wireless Standards |
IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz |
|
Dimensions ( W x D x H ) |
225×145.5×37 in (400×255×72 mm) |
|
Antenna Type |
4 Fixed High Performance Antennas |
|
WIRELESS FEATURES |
|
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz |
|
Reception Sensitivity |
5 GHz: |
|
|
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm |
|
|
11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm |
|
|
11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm |
|
|
11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm |
|
|
|
|
|
2.4 GHz: |
|
|
11g 54Mbps: -78 dBm |
|
|
11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm |
|
|
11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm |
|
Transmit Power |
CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz) |
|
|
FCC: <30dBm(2.4GHz&5GHz) |
|
Wireless Modes |
Access Point, Range Extender, Client, Multi-SSID |
|
Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control |
|
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions |
|
DHCP |
Server, DHCP Client List |
|
Quality of Service |
WMM |
|
Advanced Functions |
Captive Portal |
|
OTHERS |
|
|
Certification |
CE, FCC, RoHS |
|
Package Contents |
Wireless Access Point TL-WA1201 |
|
|
Power Adapter |
|
|
RJ45 Ethernet Cable |
|
|
Quick Installation Guide |
|
|
PoE Power Injector |
|
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, |
|
|
10, MAC OS, NetWare, UNIX or Linux |
|
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other |
|
|
Java-enabled browser |
|
Environment |
Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F) |
|
|
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
|
|
Operating Humidity: 10%~90% non-condensing |
|
|
Storage Humidity: 5%~90% non-condensing |
|
Protocol Support |
IPv4, IPv6 |
