ASUS ZenWiFi AX XT8 - AX6600 Whole-Home Tri-band Mesh Wi-Fi 6 System 1 Pack - White

ASUS ZenWiFi AX XT8 - AX6600 Whole-Home Tri-band Mesh Wi-Fi 6 System 1 Pack - White

Tri-Band Wi-Fi 6 System for High-Speed Performance

The ASUS ZenWiFi AX XT8 is a tri-band Wi-Fi 6 system that delivers AX6600 speeds, ensuring fast and reliable internet connections for your entire home.

With three dedicated bands, it provides a high-performance network, capable of handling multiple devices simultaneously without compromising speed.

Designed for Optimal Airflow and Heat Management

This system is built with specially designed vents to increase airflow and a double heatsink for enhanced heat dissipation.

These features help keep the system cool during heavy use, ensuring optimal performance without overheating.

45° Antennas for Multi-Story Home Coverage

The ZenWiFi AX XT8 features strategically placed 45° antennas that ensure strong and consistent Wi-Fi coverage throughout multi-story homes.

This design helps eliminate dead zones and maintains a stable connection across all levels of your house.

Vertical Housing for Signal Integrity

The router’s vertical housing, with space between the antennas and the circuit board, reduces interference and ensures minimal Wi-Fi signal disruption.

This thoughtful design contributes to more stable and efficient wireless connections.

2.5G WAN/LAN Port for Enhanced Wired Connectivity

Equipped with a 2.5G WAN/LAN port, the ZenWiFi AX XT8 allows for ultra-fast wired connections, ideal for bandwidth-heavy activities like 4K streaming or gaming.

This high-speed port enhances the overall network experience, providing flexibility for high-speed internet access.

Wi-Fi Data Rate

574 Mbps (2.4 GHz) + 1201 Mbps (5 GHz-1) + 4804 Mbps (5 GHz-2)

Product Segment

AX6600 ultimate AX performance

Transmit/Receive

2.4 GHz 2x2, 5 GHz-1 2x2, 5 GHz-2 4x4

Memory

256 MB Flash, 512 MB RAM

Operating Frequency Bands

2.4 GHz, 5 GHz-1, 5 GHz-2

Operating Modes

Wireless Router Mode, Access Point Mode

I/O Ports

1 x RJ45 for 2.5G BaseT WAN, 3 x RJ45 for Gigabit LAN, 1 x USB 3.1 Gen 1

Buttons

WPS Button, Reset Button, Power Switch

LED Indicators

Power x 1

Power Supply

AC Input: 110V240V (5060Hz), DC Output: 12V with max. 1.75A, 19V with max. 1.75A

Package Content

ZenWiFi AX, RJ-45 Cable, Power Adapter, Quick Start Guide, Warranty Card

Dimensions

160 x 75 x 161.5 mm

Parental Controls

Safe Browsing, Block access to unwanted websites and apps, Time Scheduling

Router APP

ASUS Router APP

Guest Network

Maximum 9 rules, Guest Network Time Limit

Security Features

WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise, WPS, Let's Encrypt, DNS-over-TLS, Firewall

VPN Support

VPN Client L2TP, OpenVPN, PPTP, WireGuard, VPN Server IPSec, Open VPN, PPTP, WireGuard

Traffic Control

Adaptive QoS, Traffic Monitor, Traffic Analyzer

WAN Features

Dual WAN, 3G/4G LTE Dongle, DMZ, DDNS

LAN Features

IGMP Snooping, IPTV, Wake on LAN (WOL)

Wireless Features

UTF-8 SSID, Wi-Fi MAC Address Filter (Max 64 rules), Wireless Scheduler, Airtime Fairness, Universal Beamforming, Explicit Beamforming

USB Application

AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server

Administration

Diagnosis Tools, Feedback System, System Log, Auto Firmware Update, New Device Connect Notification, Connection Diagnosis, Login Captcha
