TP-Link BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

TP-Link BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

Next-Gen Wi-Fi 7

Enjoy a smooth network with higher throughput and lower interference.

Multi-Link Operation (MLO)

Enables devices to simultaneously send and receive data across different frequency bands and channels.

Omada Mesh Technology

More flexible and convenient wireless deployment.

Intelligent Power Management

Offers more reliable network operation for your business.

Supersized Throughput for Better Experiences

With the brand-new 6 GHz band open to applications, WiFi 7 supports extending channel width to 320 MHz. Compared to WiFi 6/6E, the doubled channel bandwidth of 6 GHz offers many more simultaneous transmissions at the fastest possible speeds. ^‡ Making full use of these new resources, the throughout of EAP773 reaches up to 9214 Mbps.

Higher Capacity for Increased Traffic Demands

WiFi 7 supports 4096-QAM with 12 bits rather than WiFi 6’s 10 bits. The updated modulation method enables each signal to carry more dense amounts of data. Equipped with advanced 4096-QAM, EAP773 empowers your business to meet ever-growing traffic demands from high-bandwidth applications, such as remote offices, HD video conferencing, and cloud-based applications.

Lower Latency for Boosted Network Reliability

EAP773 allows network devices to communicate across multiple bands and channels simultaneously thanks to Multi-Link Operation (MLO). Additionally, Multi Resource Units (Multi-RUs) open up previously wasted channels. More bands can be used concurrently to share redundant data, and the interference will be blocked to improve reliability.

Optimized Wired Performance with 10G PoE+ Port

With a 10 Gigabit Ethernet Port, EAP773 delivers remarkable multi-gigabit performance for higher bandwidth and faster WiFi. Compatibility with 802.3at PoE is ideal for flexible deployment in large-scale scenes such as offices, schools, and hotels.

Auto Channel Selection and Power Adjustment

Provide powerful wireless performance while greatly reducing Wi-Fi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.

Seamless Integration into Omada SDN

The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface. Experience total control at your fingertips.

Interface

1× 10G Ethernet Port

Button

Reset

Power Supply

802.3at PoE or 12V/2.5A DC

Notice: Due to the software update, the power supply has been updated from 802.3bt to 802.3at.

Power Consumption

24.05 W (For PoE);

20.92 W (For DC)

Dimensions ( W x D x H )

8.7 × 8.7 × 1.3" (220 × 220 × 32.5mm)

Antenna Type

2.4 GHz: 2× 4.0 dBi

5 GHz: 2× 5.0 dBi

6 GHz: 2× 5.0 dBi

Bluetooth

1 × 4.0 dBi, Bluetooth 5.2

Firmware update may be required.

Mounting

Ceiling / Wall Mounting (Kits Included)

Coverage

140 ㎡(1500 ft²)

Concurrent Clients

380+

Wireless Standards

IEEE 802.11 a/b/g/n/ac/ax/be

Frequency

6 GHz, 5 GHz, and 2.4 GHz

Signal Rate

574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz)†

Wireless Functions

MLO‡

4K-QAM‡

Seamless Roaming(802.11k/v/r)

MU-MIMO (2*2 DL/UL MU-MIMO)

HE320

 Mesh△

BSS Coloring

OFDMA

Load Balance

Band Steering

Beamforming

Airtime Fairness

Multiple SSIDS:24(8 on each band)

Wireless Schedule

Reboot Schedule

QoS(WMM)

Rate Limit

Static IP/Dynamic IP

RADIUS Accounting

MAC Authentication

Wireless Security

Captive Portal Authentication△

Access Control

Maximum number of MAC Filter: 4,000

Wireless Isolation Between Clients

VLAN

Rogue AP Detection

WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power

< 20 dBm (2.4 GHz, EIRP)

< 23 dBm (5 GHz, band 1&band 2, EIRP)

< 28 dBm (5 GHz, band 3, EIRP)

< 23dBm (6 GHz, EIRP)

Omada App

Yes

Centralized Management

Omada Cloud-Based Controller

Omada Hardware Controller (OC300)

Omada Hardware Controller (OC200)

Omada Software Controller

Cloud Access

Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.

Email Alerts

Yes

LED ON/OFF Control

Yes

Management MAC Access Control

Yes

SNMP

v1, v2c, v3

System Logging Local/Remote Syslog

Yes

Web-based Management

Yes

Certification

CE, FCC, RoHS, IC
