Asus Prime AMD Radeon RX 9070 XT 16GB GDDR6 OC Edition Graphic Card

Asus Prime AMD Radeon RX 9070 XT 16GB GDDR6 OC Edition Graphic Card

2.5-slot Design

The Prime Radeon RX 9070 XT features a 2.5-slot layout that optimizes the arrangement of the shroud, heatsink, and heat pipes, allowing the three Axial-tech fans to leverage side-panel ventilation and maintain excellent thermal performance.

Axial-tech Upgrades

Three Axial-tech fans with smaller hubs and longer blades, combined with a barrier ring, improve downward air pressure, reduce noise, and enhance overall cooling efficiency.

Phase-Change GPU Thermal Pad

A premium phase-change thermal pad melts to fill gaps between the GPU and thermal module, providing superior thermal conductivity and better heat dissipation under heavy workloads.

MaxContact Design

The MaxContact manufacturing process increases the heat spreader surface area by 5%, improving thermal transfer and lowering temperatures by up to 2°C when combined with the heatsink array and Axial-tech fans.

What are the benefits of Asus Prime AMD Radeon RX 9070 XT 16GB GDDR6 OC Edition Graphic Card?

Maintains lower GPU temperatures and stable performance through a 2.5-slot thermal design that improves airflow efficiency while fitting in most standard PC cases.

Delivers quieter and more effective cooling thanks to upgraded Axial-tech fans that increase air pressure and reduce turbulence.

Improves heat transfer and sustained performance under heavy gaming or creative workloads using a phase-change thermal pad that fills microscopic gaps for better conductivity.

Enhances overall cooling efficiency and reliability with MaxContact technology, increasing heat spreader contact area to reduce operating temperatures and thermal throttling.

GPU

AMD Radeon RX 9070 XT

Bus Standard

PCI Express 5.0

Video Memory

16 GB GDDR6

Memory Interface

256‑bit

Memory Speed

20 Gbps

Stream Processors

4096

Engine Clock (OC Mode)

Boost up to 3030 MHz / Game up to 2480 MHz

Engine Clock (Default)

Boost up to 3010 MHz / Game up to 2460 MHz

OpenGL Support

OpenGL 4.6

Display Outputs

1× HDMI 2.1b, 3× DisplayPort 2.1a

Maximum Resolution

7680 × 4320

Maximum Displays Supported

4

Power Connectors

3× 8‑pin

Recommended PSU

750 W

Dimensions

312 × 130 × 50mm

Slot Size

2.5 slots
