CPU Socket
|
Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold, and Celeron® Processors* | Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
|
Chipset
|
Intel® Z790 Chipset
|
Memory
|
4 x DIMM slots, max. 192GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory* | Dual channel memory architecture | Supports Intel® Extreme Memory Profile (XMP) memory module | ASUS Enhanced Memory Profile II (AEMP II) | Supports DIMM Flex | *Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration,*Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
|
Graphics
|
1 x HDMI™ port** | 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs*** | *Graphics specifications may vary between CPU types. | **Supports 4K@60Hz as specified in HDMI 2.1. | ***VGA resolution support depends on processors' or graphic cards' resolution.
|
Expansion Slots
|
Intel® Core™ Processors (14th & 13th & 12th Gen)* | 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)** | Intel® Z790 Chipset | 1 x PCIe 4.0 x4 slot | *Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/). | **M.2_1 shares bandwidth with PCIEX16(G5)_2. When M.2_1 is enabled, PCIEX16(G5)_2 will be disabled and PCIEX16(G5)_1 will run x8 only. | ***To ensure compatibility of the device installed
|
Storage
|
Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports* | Intel® CoreTM Processors (14th & 13th & 12th Gen) | M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)** | M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) | Intel® Z790 Chipset | M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) | M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) | M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) | 4 x SATA 6Gb/s ports | *Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. | **M.2_1 shares bandwidth with PCIEX16(G5)_2. When M.2_1 is enabled, PCIEX16(G5)_2 will be disabled and PCIEX16(G5)_1 will run x8 only.
|
Ethernet
|
1 x Realtek 5Gb Ethernet | ASUS LANGuard
|
Wireless & Bluetooth
|
Intel® Wi-Fi 7* | 2x2 Wi-Fi 7 (802.11be) | Supports 2.4/5/6GHz frequency band* | Support Wi-Fi 7 320MHz bandwidth, up to 5.76Gbps transfer rate. | Bluetooth® v5.4**** | *Compatible with Windows 11 or later. | **Wi-Fi 7 MLO(Multi-link Operation) full functions support will be ready in Windows 11 2024 Platform (Windows 11 24H2) or later. | ***Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries. | ****The Bluetooth version may vary.
|
USB
|
Rear USB (Total 12 ports) | 2 x Thunderbolt™ 4 ports (2 x USB Type-C®) | 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®) | 4 x USB 5Gbps ports (4 x Type-A) | Front USB (Total 9 ports) | 1 x USB 20Gbps connector (supports USB Type-C® with up to 60W PD/QC4+)** | 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports | 2 x USB 2.0 headers support 4 additional USB 2.0 ports | *USB Type-C® power delivery output: max. 5V/3A | **USB Type-C® power delivery output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A
|
Audio
|
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 | - Impedance sense for front and rear headphone outputs | - Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking | - High quality 120 dB SNR stereo playback output and 110 dB SNR recording input | - Supports up to 32-Bit/384 kHz playback on front panel" | Audio Features | - SupremeFX Shielding Technology | - ESS® ES9218 QUAD DAC | - Gold-plated audio jacks | - Rear optical S/PDIF out port | - Premium audio capacitors | *The LINE OUT port on the rear I/O does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
|
Back Panel I/O Ports
|
1 x Thunderbolt™ 4 port (2 x USB Type-C®) | 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®) | 4 x USB 5Gbps ports (4 x Type-A) | 1 x DisplayPort | 1 x HDMI™ port | 1 x Intel® 2.5Gb Ethernet | 1 x Optical S/PDIF out port | 1 x Wi-Fi 6E/6 module | 5 x Gold-plated audio jacks | 1 x BIOS FlashBack™ button | 1 x Clear CMOS button
|
Internal I/O Connectors
|
Fan and Cooling related | 1 x 4-pin CPU Fan header | 1 x 4-pin CPU OPT Fan header | 1 x 4-pin AIO Pump header | 4 x 4-pin Chassis Fan headers | 1 x 4-pin VRM heatsink fan header | Power related | 1 x 24-pin Main Power connector | 2 x 8-pin +12V Power connector | Storage related | 2 x M.2 slots (Key M) | 1 x M.2 slot (Key E) | 8 x SATA 6Gb/s ports | 1 x SATA 6Gb/s port (RAID 0, 1, 5, 10 support) | USB | 1 x USB 20Gbps connector (supports USB Type-C® with up to 100W PD/QC4+) | 1 x USB 5Gbps header supports 2 additional USB 5G ports | 2 x USB 2.0 headers support 4 additional USB 2.0 ports | Miscellaneous | 3 x Addressable Gen 2 headers | 1 x RGB header | 1 x CPU Over Voltage jumper | 1 x Front Panel Audio header (F_AUDIO) | 1 x Start button | 1 x 20-3 pin System Panel header with Chassis intrude function | 1 x Thermal Sensor header | 1 x Thunderbolt™ (USB4®) header
|
Special Features
|
ROG Exclusive Software | ROG CPU-Z | DTS® Sound Unbound | ASUS Exclusive Software | Armoury Crate | AIDA64 Extreme (60 days free trial) | Aura Creator | Aura Sync | Fan Xpert 4 (with AI Cooling II) | GameFirst | Power Saving | Sonic Studio | Two-Way AI Noise Cancelation | AI Suite 3 | Easy Optimization with AI Overclocking | TPU | DIGI+ VRM | Turbo app | PC Cleaner | MyASUS | USB Wattage Watcher | Intel® Unison™ | Adobe Creative Cloud (Free Trial) | Norton 360 for Gamers (60 Days Free Trial) | WinRAR (40 Days Free Trial) | UEFI BIOS | AI Overclocking Guide | ASUS EZ DIY | ASUS CrashFree BIOS 3 | ASUS EZ Flash 3 | ASUS UEFI BIOS EZ Mode | ASUS MyHotkey | FlexKey | MemTest86
|
BIOS
|
256 Mb Flash ROM, UEFI AMI BIOS
|
Manageability
|
WOL by PME, PXE
|
Accessories
|
Cables | 2 x SATA 6Gb/s cables | 1 x Fan Bracket and 1 x Fan cable for liquid cooler | Installation kit | 1 x CPU installation tool | Miscellaneous | 1 x ROG graphics card holder | 1 x ROG STRIX stickers | 1 x ROG keychain | 1 x CableMod coupon code | 1 x ROG frame sticker | 1 x ROG MultiKey | 1 x M.2 SSD screw package | 1 x Q-Connector | 1 x Wi-Fi Antenna | 1 x Extension cable for Addressable LED | 1 x ASUS 2x2 dual band Wi-Fi moving antenna | 1 x Extension cable for RGB strips (80 cm) | 1 x ROG Thank you card | 1 x User manual
|
Operating System
|
Windows® 11, Windows® 10 64-bit
|
Form Factor
|
ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
|
