CPU
|
AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors
|
Chipset
|
AMD X670
|
Memory
|
4 x DIMM, Max. 128GB, DDR5
|
|
|
6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/
|
|
|
5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory
|
|
|
Dual Channel Memory Architecture
|
|
|
Supports AMD EXTended Profiles for Overclocking (EXPO)
|
|
|
OptiMem II
|
|
|
Supported memory types, data rate(Speed),and number of DRAM module vary depending on the CPU and memory configuration
|
|
|
Non-ECC, Un-buffered DDR5 Memory supports
|
|
|
On-Die ECC function
|
Graphics
|
1 x DisplayPort
|
|
|
1 x HDMI port
|
|
|
Supports max. 8K@60Hz as specified in DisplayPort 1.4
|
|
|
Supports 4K@60Hz as specified in HDMI 2.1
|
Expansion Slots
|
AMD Ryzen 7000 Series Desktop Processors
|
|
|
2 x PCIe 5.0 x16 slots (supports x16 or x8/x4 modes)
|
|
|
AMD X670 Chipset
|
|
|
1 x PCIe 4.0 x16 slot (supports x4 mode)
|
Storage
|
Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
|
|
|
AMD Ryzen 7000 Series Desktop Processors
|
|
|
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
|
|
|
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
|
|
|
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode))
|
|
|
AMD X670 Chipset
|
|
|
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
|
|
|
4 x SATA 6Gb/s ports
|
|
|
AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
|
Ethernet
|
1 x Intel 2.5Gb Ethernet
|
|
|
ASUS LANGuard
|
Wireless & Bluetooth
|
Wi-Fi 6E
|
|
|
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
|
|
|
Supports 2.4/5/6GHz frequency band
|
|
|
Bluetooth v5.2
|
USB
|
Rear USB (Total 13 ports)
|
|
|
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
|
|
|
12 x USB 3.2 Gen 2 ports (10 x Type-A + 2 x
|
|
|
USB Type-C)
|
|
|
Front USB (Total 9 ports)
|
|
|
1 x USB 3.2 Gen 2x2 connector
|
|
|
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
|
|
|
3 x USB 2.0 headers support additional 6 USB 2.0 ports
|
Audio
|
ROG SupremeFX 7.1 Surround Sound High
|
|
|
Definition Audio CODEC ALC4080
|
|
|
- Impedance sense for front and rear
|
|
|
headphone outputs
|
|
|
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
|
|
|
- High quality 120 dB SNR stereo playback
|
|
|
output and 113 dB SNR recording input
|
|
|
- Supports up to 32-Bit/384 kHz playback
|
Audio Features
|
- Audio Shielding
|
|
|
- Savitech SV3H712 AMP
|
|
|
- Gold-plated audio jacks
|
|
|
- Rear optical S/PDIF out port
|
|
|
- Premium audio capacitors
|
|
|
- Audio cover
|
|
|
* A chassis with an HD audio module in the
|
|
|
front panel is required to support 7.1 Surround Sound audio output.
|
Back Panel I/O Ports
|
1 x USB 3.2 Gen 2x2 port (1 x Type-C)
|
|
|
12 x USB 3.2 Gen 2 ports (10 x Type-A, 2 x USB
|
|
|
Type-C)
|
|
|
1 x DisplayPort
|
|
|
1 x HDMI port
|
|
|
1 x Wi-Fi Module
|
|
|
1 x Intel® 2.5Gb Ethernet port
|
|
|
5 x Gold-plated audio jacks
|
|
|
1 x Optical S/PDIF out port
|
|
|
1 x BIOS FlashBack button
|
|
|
1 x Clear CMOS button
|
Internal I/O Connectors
|
Fan and Cooling related
|
|
|
1 x 4-pin CPU Fan header
|
|
|
1 x 4-pin CPU OPT Fan header
|
|
|
1 x 4-pin AIO Pump header
|
|
|
5 x 4-pin Chassis Fan header
|
|
|
Power related
|
|
|
1 x 24-pin Main Power connector
|
|
|
2 x 8-pin +12V Power connector
|
|
|
Storage related
|
|
|
4 x M.2 slots (Key M)
|
|
|
4 x SATA 6Gb/s ports
|
|
|
USB
|
|
|
1 x USB 3.2 Gen 2x2 connector (supports USB Type-C)
|
|
|
1 x USB 3.2 Gen 1 header supports
|
|
|
additional 2 USB 3.2 Gen 1 ports
|
|
|
3 x USB 2.0 headers support additional 6 USB 2.0 ports
|
|
|
Miscellaneous
|
|
|
3 x Addressable Gen 2 headers
|
|
|
1 x AURA RGB header
|
|
|
1 x Alteration Mode Switch
|
|
|
1 x CPU Over Voltage jumper
|
|
|
1 x Front Panel Audio header (AAFP)
|
|
|
1 x Start button
|
|
|
1 x 20-3 pin System Panel header with Chassis intrude function
|
|
|
1 x Thermal Sensor header
|
|
|
1 x Thunderbolt™ header
|
Special Features
|
Extreme Engine Digi+
|
|
|
- 5K Black Metallic Capacitors
|
|
|
ASUS Q-Design
|
|
|
- M.2 Q-Latch
|
|
|
- PCIe Slot Q-Release
|
|
|
- Q-Code
|
|
|
- Q-DIMM
|
|
|
- Q-LED (CPU [red], DRAM [yellow], VGA
|
|
|
[white], Boot Device [yellow green])
|
|
|
- Q-Slot
|
|
|
ASUS Thermal Solution
|
|
|
- M.2 heatsink backplate
|
|
|
- M.2 heatsink
|
|
|
- VRM heatsink design
|
|
|
- Massive M.2 Heatsink
|
|
|
ASUS EZ DIY
|
|
|
- BIOS FlashBack button
|
|
|
- BIOS FlashBack™ LED
|
|
|
- Clear CMOS button
|
|
|
- ProCool II
|
|
|
- Pre-mounted I/O shield
|
|
|
- SafeSlot
|
|
|
- SafeDIMM
|
|
|
AURA Sync
|
|
|
- AURA RGB header
|
|
|
- Addressable Gen 2 headers
|
Software Features
|
ROG Exclusive Software
|
|
|
- GameFirst VI
|
|
|
- ROG CPU-Z
|
|
|
- Sonic Studio III + Sonic Studio Virtual
|
|
|
Mixer + Sonic Suite Companion
|
|
|
- Sonic Radar III
|
|
|
- DTS Sound Unbound
|
|
|
- Anti-virus software
|
|
|
ASUS Exclusive Software
|
|
|
Armoury Crate
|
|
|
- AIDA64 Extreme (60 days free trial)
|
|
|
- AURA Creator
|
|
|
- AURA Sync
|
|
|
- Fan Xpert 4 (with AI Cooling II)
|
|
|
- Power Saving
|
|
|
- Two-Way AI Noise Cancellation
|
|
|
AI Suite 3
|
|
|
- TPU
|
|
|
- DIGI+ VRM
|
|
|
- Turbo app
|
|
|
- PC Cleaner
|
|
|
MyAsus
|
|
|
WinRAR
|
|
|
UEFI BIOS
|
|
|
ASUS EZ DIY
|
|
|
- ASUS CrashFree BIOS 3
|
|
|
- ASUS EZ Flash 3
|
|
|
- ASUS UEFI BIOS EZ Mode
|
|
|
Dynamic OC Switcher
|
|
|
FlexKey
|
BIOS
|
256 MbFlash ROM, UEFI AMI BIOS
|
Manageability
|
WOL by PME, PXE
|
Accessories
|
Cables
|
|
|
2x SATA 6Gb/s cables
|
|
|
Additional Cooling Kit
|
|
|
1 x Thermal pad for M.2
|
|
|
Miscellaneous
|
|
|
1 x ASUS Wi-Fi moving antennas
|
|
|
1 x Cable ties pack
|
|
|
1 x Massive M.2 Heatsink
|
|
|
1 x M.2 Q-Latch package for M.2 backplate
|
|
|
1 x M.2 Q-Latch package
|
|
|
1 x ROG Graphics card holder
|
|
|
2 x Rubber Packages for M.2
|
|
|
1 x Rubber Package for M.2 backplate
|
|
|
1 x ROG key chain
|
|
|
1 x ROG Strix sticker
|
|
|
1 x ROG Strix thank you card
|
|
|
Documentation
|
|
|
1 x User guide
|
Operating System
|
Windows 11 64-bit, Windows 10 64-bit
|
Form Factor
|
ATX Form Factor
|
|
|
12'' x 9.6'' ( 30.5 cm x 24.4 cm )
|
